產品描述Product description
◆MSA(DA7-6/1, DA7-6/2)系列(lie)是一款(kuan)標準型的微(wei)動(dong)開關，用(yong)途極廣，適用(yong)于各類小(xiao)功率(lv)交流和直流電(dian)動(dong)工具(ju)和園林(lin)工具(ju)，如：電(dian)動(dong)釘槍、電(dian)動(dong)噴槍、打草機、修(xiu)枝機(也叫(jiao)綠籬(li)機、籬(li)笆剪)等。
◆MSA(DA7-6/1, DA7-6/2)?series are one standard type micro switches, commonly for use in low rated AC and DC powe r-tools or gardening tools, such as Electric Tackers, Electric S prayers, Grass Trimmers, Hedge Trimmers, etc.
產品特征Features
◆可選(xuan)帶以(yi)下(xia)功能 Optional with the function as follows:
→單極常(chang)開 SPNO (Single Pole Normally Open)
→單(dan)極常閉常開 SPCO (Single Pole Close and Open)
→單極(ji)常閉(bi) SPNC (Single Pole Normally Close)
→雙極常開 DPNO (Double Pole Normally Open)
→雙極(ji)常(chang)閉常(chang)開(kai) DPCO (Double Pole Close and Open)
→雙極常(chang)閉(bi) DPNC (Double Pole Normally Close)
◆可選附(fu)帶以下附(fu)件 Optional with the accessories as follows:
→壓柄(bing) Push Handle
技術數據Technical data
→機械耐久壽(shou)命 Mechanical life endurance≥1E5
→電(dian)氣耐久壽命 Electrical life endurance≥5E4
→最大沖擊電流 Max. Inrush current36A
→接(jie)觸電阻 Contact resistance≤30m Ohm
→絕緣電阻(zu) Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電(dian)強度 Dielectric strength of reinforced3000V
→環境溫(wen)度(du) Ambient temperature0°C~85°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→適用于II類防護(hu)器具 Suitable for appliances of protection class II
端子類型Terminals
◆COM, NO, NC端子 Terminals:
→插片端子 Plug-in terminals 4.8×0.6mm
→焊接(jie)端子 Solder terminals
電氣參數和認證 Electric Rating and Certification
