產品特征Features
◆可選附帶以下功能(neng) Optional with the function as follows:
→單極(ji)常開 SPNO (Single Pole Normally Open)
→單極(ji)常閉 SPNC (Single Pole Normally Close)
→單極(ji)常(chang)(chang)閉(bi)常(chang)(chang)開 SPCO (Single Pole Close and Open)
→雙(shuang)極常開 DPNO (Double Pole Normally Open)
→雙極常(chang)閉 SPNC (Double Pole Normally Close)
→雙極常閉常開 SPCO (Double Pole Close and Open)
→雙極(ji)常閉常開異步 SPCO?asynchronously?(Double Pole Close and Open?asynchronously)
→一極常開，另一極常閉(bi) One Pole NO, the Other NC
→一極常(chang)(chang)開，另一極常(chang)(chang)閉常(chang)(chang)開 One Pole NO, the Other CO
◆可選附帶以(yi)下附件 Optional with the accessories as follows:
→壓柄 Push Handle
→密封圈(quan) SealRing
技術數據Technical data
→機(ji)械(xie)耐久(jiu)壽命(ming) Mechanical life endurance≥5E4 / 1E5
→電氣耐久壽命 Electrical life endurance≥1E4 / 5E4
→最(zui)大沖擊(ji)電流 Max. Inrush current at 250V84A
→最(zui)大沖(chong)擊電流(liu) Max. Inrush currentat 125V120A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基(ji)本介電強度 Dielectric strength of function500V / 1500V
→加強介電強度(du) Dielectric strength of reinforced500V /?3000V
→環(huan)境溫度 Ambient temperature0°C~55°C
→環境溫度(du) Ambient temperature-25°C~125°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→適(shi)用于II類防(fang)護器具 Suitable for appliances of protection class II
→開(kai)關操作(zuo)力選擇范圍(wei) Operating force range3N~15N
→開關內(nei)部觸點間隙 Contact gap?range0.8~3.0mm
端子類型Terminals
◆COM, NO, NC端子(zi) Terminals:
→插片端子 Plug-in terminals 6.3×0.8mm
→插片端子 Plug-in terminals 4.8×0.8mm
→插片端子 Plug-in terminals 4.8×0.5mm
→焊接(jie)端子 Solder terminals
→線路板(ban)焊接端(duan)子 PCB Solder terminals
★本產品榮獲多項實用(yong)新(xin)型專(zhuan)利(li)(li)，專(zhuan)利(li)(li)號：ZL201921788022.3，ZL201920465989.1
★Utility Models patented with the no. is?ZL201921788022.3,?ZL201920465989.1
