產品特征Features
◆可(ke)選附帶以下功能(neng) Optional with the function as follows:
→單極常開 SPNO (Single Pole Normally Open)
→單極常(chang)閉 SPNC (Single Pole Normally Close)
→單極常閉常開 SPCO (Single Pole Close and Open)
→雙極常開 DPNO (Double Pole Normally Open)
→雙(shuang)極常閉 SPNC (Double Pole Normally Close)
→雙(shuang)極常(chang)閉常(chang)開 SPCO (Double Pole Close and Open)
→雙極常閉常開異步 SPCO?asynchronously?(Double Pole Close and Open?asynchronously)
→一(yi)極(ji)常開，另一(yi)極(ji)常閉 One Pole NO, the Other NC
→一極常(chang)開，另一極常(chang)閉常(chang)開 One Pole NO, the Other CO
◆可選附帶以下附件 Optional with the accessories as follows:
→壓(ya)柄 Push Handle
→密封圈(quan) SealRing
技術數據Technical data
→機械(xie)耐(nai)久壽命 Mechanical life endurance≥5E4 / 1E5
→電(dian)氣(qi)耐(nai)久壽命 Electrical life endurance≥1E4 / 5E4
→最(zui)大沖(chong)擊電流 Max. Inrush current at 250V84A
→最大沖(chong)擊電流(liu) Max. Inrush currentat 125V120A
→接(jie)觸(chu)電阻 Contact resistance≤30m Ohm
→絕(jue)緣(yuan)電阻 Insulation resistance≥7M Ohm
→基本介電(dian)強度 Dielectric strength of function500V / 1500V
→加(jia)強(qiang)介電強(qiang)度 Dielectric strength of reinforced500V /?3000V
→環境溫度 Ambient temperature0°C~55°C
→環境溫度 Ambient temperature-25°C~125°C
→阻燃等(deng)級(ji) FlammabilityUL 94V-0
→防(fang)護等級 Protection typeIP40
→適用于II類防護器具 Suitable for appliances of protection class II
→開關操作力選擇范圍 Operating force range3N~15N
→開關內部觸點間隙 Contact gap?range0.8~3.0mm
端子類型Terminals
◆COM, NO, NC端子 Terminals:
→插片端子(zi) Plug-in terminals 6.3×0.8mm
→插(cha)片端子 Plug-in terminals 4.8×0.8mm
→插片端子 Plug-in terminals 4.8×0.5mm
→焊接(jie)端子 Solder terminals
→線路板焊接端子 PCB Solder terminals
★本(ben)產品榮獲多項實用新(xin)型(xing)專利，專利號(hao)：ZL201921788022.3，ZL201920465989.1
★Utility Models patented with the no. is?ZL201921788022.3,?ZL201920465989.1
