◆DR2-6E系列是一款通用型的轉盤電子調速器，是FR-6E系列的迷你版本(ben)，應用于(yu)各(ge)類手持(chi)電(dian)(dian)(dian)動工(gong)具(ju)，如：電(dian)(dian)(dian)錘、曲(qu)線鋸、往復鋸、100和125角向磨(mo)光(guang)機(ji)(ji)、,拋光(guang)機(ji)(ji)、攪拌(ban)器(qi)、電(dian)(dian)(dian)木銑(xian)、砂光(guang)機(ji)(ji)、模具(ju)電(dian)(dian)(dian)磨(mo)等(deng)。
◆DR2-6E series are one general type AC Dial Wheel Speed Controls, the mini-type of FR-6E series, for popular used in portable power-tools such as: Rotary Hammer, Jig Saws, Reciprocating Saws, 100mm and 125mm Angle Grinders, Polisher Grinders, Electric Routers, Sanders, Die Grinders, etc.◆可選帶以下功能(neng) Optional with following function:
→全波調速 Full-wave s peed control
→半波(bo)調速 Half-wave speed control
→On-Off通斷功能帶(dai)可變(bian)電阻輸出 On-off version with Passive linear potentiometer
◆可選帶以下(xia)附(fu)件 Optional with the accessories as follows:
→初(chu)始電壓微調節旋鈕 Knob for adjusting start voltage
→可(ke)控硅外置(zhi)適合(he)更大(da)電流并可(ke)附帶(dai)散熱片
→External Triac version for high currents additional with heat sink
→機械耐久壽命 Mechanical life endurance≥1E5
→電氣耐久壽命 Electrical lifeendurance≥5E4
→最大電流 Max. current at 250V8A
→最大電流 Max. current at 125V12A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 Flammability UL 94V-0
→防護等級 Protection type IP40
→開(kai)關(guan)內部電子部分(fen)在相(xiang)(xiang)應(ying)使用中一(yi)并(bing)做過相(xiang)(xiang)關(guan)測試，本(ben)開(kai)關(guan)適合做二類器具開(kai)關(guan)使用。
→The electronics in the switches are to be tested together with the corresponding appliance, the switches are suitable for appliance of class II.
◆輸入端(duan)/輸出端(duan) Input side/Output side:
→導線(xian)端子 Wires terminals AWG14 ~ AWG18.
