產品描述Product description
◆DLK系列是一款(kuan)專用型的直流扳機開(kai)關，集成(cheng)防塵和機械(xie)剎車(che)接(jie)點(dian)，應用于各類充(chong)(chong)(chong)電(dian)式(shi)(shi)手持電(dian)動(dong)工具(ju)和電(dian)動(dong)園林工具(ju)，如：充(chong)(chong)(chong)電(dian)式(shi)(shi)電(dian)鉆(zhan)、充(chong)(chong)(chong)電(dian)式(shi)(shi)電(dian)錘、充(chong)(chong)(chong)電(dian)式(shi)(shi)螺(luo)絲起子(zi)、充(chong)(chong)(chong)電(dian)式(shi)(shi)沖擊扳手、充(chong)(chong)(chong)電(dian)式(shi)(shi)打草機(ji)、充(chong)(chong)(chong)電(dian)式(shi)(shi)吹吸機(ji)等，也(ye)可應用各類直(zhi)流無刷電動工(gong)具。
◆DLK series are one special type DC trigger switches, ;integrated dustproof and mechanical brake contact, optional with inner reversing structure, commonly for used in DC cordless portable power-tools and power gardening tools such as: Cordless Drills, Cordless Screw Drivers, Cordless Rotary Hammers, Cordless Impact Wrenches, Cordless Grass Trimmers, Cordless Blowers, etc. Besides, they also suitable for brushless DC tools.
產品特征Features
◆本開關結(jie)構緊湊，可選帶以下功能或附件：
→通斷(duan)功能帶電位器輸(shu)出
→通斷功能(neng)帶機械換向和電位器(qi)輸出(有刷(shua)直流工具專用)
→通斷功能帶(dai)正(zheng)反轉信(xin)號和電(dian)位器輸出(無刷直流工具專用)
→通斷(duan)功能(neng)帶(dai)正(zheng)反轉霍爾(er)信號和電位器輸出(無刷直流工具專用)
→外接各類導(dao)線(xian)和電池夾(jia)
◆The switches combine compact size, optional with the function or accessories as follows:
→On-off with linear potentiometer output
→On-off with mechanical reversing and linear potentiometer output
→On-off with reversing signal indication potentiometer output
(Special for DC brushless applications)
→On-off with reversing hall signal and linear potentiometer output
(Special for DC brushless applications )
→Auxiliary wire or battery clamp
技術數據Technical data
→機(ji)械耐久壽命 Mechanical life endurance≥5E4/1E5
→電氣耐久壽命 Electrical life endurance≥1E4/5E4
→最大(da)電流 Max. current at 36Vd.c30A
→接觸電阻(zu) Contact resistance≤30m Ohm
→絕緣電(dian)阻 Insulation resistance≥7M Ohm
→基本介(jie)電強度 Dielectric strength of function1300V
→加強介電強度 Dielectric strength of reinforced2600V
→環境(jing)溫度(du) Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等(deng)級 Protection typeIP40
◆開關內部電子部分在相(xiang)(xiang)應使(shi)用中一并(bing)做過相(xiang)(xiang)關測試,本開關適合做二類器具開關使(shi)用.
◆The electronics in the switches had to be tested together with the corresponding appliances, so the switches are suitable for appliance of class II.
端子類型Terminals
◆輸入端 Input side:
→焊(han)接端子 Solder terminal 4.2X0.8mm
◆輸出端(duan) Outputside:
→焊(han)接端子 Solder terminal 4.6X 0.5mm
★本產品榮獲(huo)實用(yong)新型專利(li)，專利(li)號：ZL201922024096.6
★Utility Model patented with the no. is ZL201922024096.6
電氣參數和認證 Electric Rating and Certification
