產品描述Product description
◆DLK系列是(shi)一款專用型(xing)的直流扳(ban)機開關，集成(cheng)防(fang)塵和機械剎車接點，應(ying)用于(yu)各(ge)類(lei)(lei)充(chong)(chong)電(dian)(dian)式(shi)手(shou)(shou)持電(dian)(dian)動工具(ju)和電(dian)(dian)動園林工具(ju)，如：充(chong)(chong)電(dian)(dian)式(shi)電(dian)(dian)鉆、充(chong)(chong)電(dian)(dian)式(shi)電(dian)(dian)錘(chui)、充(chong)(chong)電(dian)(dian)式(shi)螺絲起子、充(chong)(chong)電(dian)(dian)式(shi)沖擊扳(ban)手(shou)(shou)、充(chong)(chong)電(dian)(dian)式(shi)打草機、充(chong)(chong)電(dian)(dian)式(shi)吹吸機等，也可(ke)應(ying)用各(ge)類(lei)(lei)直(zhi)流無刷(shua)電動工(gong)具。
◆DLK?series are one special type DC trigger switches,?integrated dustproof?and?mechanical brake contact, optional with inner reversing structure, commonly for used in DC cordless portable power-tools and power gardening tools such as: Cordless Drills,?Cordless Screw Drivers, Cordless Rotary Hammers, Cordless Impact Wrenches, Cordless Grass Trimmers, Cordless Blowers, etc. Besides, they also suitable for?brushless?DC tools.
產品特征Features
◆本開(kai)關結構(gou)緊湊(cou)，可選帶以下功能或附件：
→通(tong)斷功能帶電位器(qi)輸出
→通斷功能帶機(ji)械換向和電位器輸出(有刷直流工具專用)
→通斷(duan)功能(neng)帶正反轉信(xin)號和電位(wei)器輸出(無刷直流(liu)工具專用)
→通斷功能帶正反轉霍(huo)爾信(xin)號和電位器(qi)輸出(無刷直流工具專用)
→外接各類(lei)導線和電池夾
◆The switches combine compact size, optional with the function or accessories as follows:
→On-off with linear potentiometer output
→On-off with mechanical reversing and linear potentiometer output
→On-off with reversing signal indication potentiometer output
(Special for DC brushless applications)
→On-off with reversing hall signal and linear potentiometer output
(Special for DC brushless applications )
→Auxiliary wire or battery clamp
技術數據Technical data
→機械耐久壽(shou)命 Mechanical life endurance≥5E4/1E5
→電氣耐久壽命 Electrical life endurance≥1E4/5E4
→最大電流 Max. current at 36Vd.c30A
→接觸電(dian)阻 Contact resistance≤30m Ohm
→絕緣電阻(zu) Insulation resistance≥7M Ohm
→基本(ben)介電強度 Dielectric strength of function1300V
→加強(qiang)介電強(qiang)度 Dielectric strength of reinforced2600V
→環境(jing)溫度 Ambient temperature0°C~55°C
→阻燃(ran)等(deng)級 FlammabilityUL 94V-0
→防(fang)護等級 Protection typeIP40
◆開(kai)(kai)(kai)關內部(bu)電子部(bu)分(fen)在相(xiang)應(ying)使用中(zhong)一(yi)并做(zuo)過(guo)相(xiang)關測試,本開(kai)(kai)(kai)關適合做(zuo)二類(lei)器具開(kai)(kai)(kai)關使用.
◆The electronics in the switches had to be tested together with the corresponding appliances, so the switches are suitable for appliance of class II.
端子類型Terminals
◆輸入端 Input side:
→焊接端子(zi) Solder terminal 4.2X0.8mm
◆輸出端 Outputside:
→焊(han)接端(duan)子 Solder terminal 4.6X 0.5mm
★本產品榮獲實用新型專利，專利號(hao)：ZL201922024096.6
★Utility Model patented with the no. is ZL201922024096.6
電氣參數和認證 Electric Rating and Certification
