產品特征Features
◆本(ben)開(kai)關結構(gou)緊(jin)湊，可選帶(dai)以(yi)下功能或(huo)附件：
→電(dian)子調速功能
→智能調速功(gong)能，可選帶軟啟動(dong)、欠(qian)壓保(bao)護(hu)、過流保(bao)護(hu)、電池過溫保(bao)護(hu)等
→外(wai)接(jie)各類導線(xian)和電池夾
◆The switches combine compact size, optional with the function or accessories as follows:
→Electronics variable speed control function
→Multi-function, optional soft start, under-voltage protection, over current protection, battery temperature protection, etc.
→Auxiliary wire or battery clamp
技術數據Technical data
→機(ji)械耐久壽(shou)命 Mechanical life endurance≥5E4/1E5
→電(dian)氣耐久壽(shou)命 Electrical life endurance≥1E4/5E4
→最(zui)大電流 Max. currentat 18Vd.c20A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7MOhm
→基(ji)本介電(dian)強度 Dielectric strength of function500V
→加強(qiang)介(jie)電強(qiang)度 Dielectric strength of reinforced500V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
◆開關(guan)(guan)內部電子部分在相(xiang)應使用中一并做過相(xiang)關(guan)(guan)測試,本開關(guan)(guan)適合做二類(lei)器具開關(guan)(guan)使用.
◆The electronics in the switches had to be tested together with the corresponding appliances, so the switches are suitable for appliance of class II.
端子類型Terminals
◆輸入端 Input side:
→焊接端子 Solder terminal 4.2×0.8mm
◆輸出端 Output side:
→焊(han)接端子 Solder terminal4.6×0.5mm
