產品描述Product description
◆DPK系列是一款通用型的直流扳(ban)機(ji)開關(guan)，集成(cheng)防(fang)塵和(he)機械(xie)剎車接點，內(nei)部帶換(huan)向結構，應(ying)用(yong)于各類(lei)直(zhi)流(liu)充(chong)電(dian)(dian)式手(shou)持(chi)電(dian)(dian)動工具，如：充(chong)電(dian)(dian)式電(dian)(dian)鉆、充(chong)電(dian)(dian)式電(dian)(dian)錘、充(chong)電(dian)(dian)式電(dian)(dian)圓鋸(ju)、充(chong)電(dian)(dian)式螺絲起子、充(chong)電(dian)(dian)式沖擊扳手(shou)等，也(ye)可應(ying)用(yong)各類(lei)直(zhi)流(liu)無刷電(dian)動(dong)工具。
◆DPK series are general type DC trigger switches, integrated dustproof, mechanical brake conta ct and reversing box, commonly for used in DC cordless portable power-tools such as: Cordless Drills, Cordless Screw Drivers, Cordless Rotary Hammers, Cordless Impact Wrenches, etc. Besides, they also suitable for DC Cordless brushless DC tools.
產品特征Features
◆可選帶以下功能或附件:
→通斷帶電位器輸出功能
→通斷帶正反轉信號和電位器輸出功能(無(wu)刷直(zhi)流(liu)電機(ji)專用)
→通斷帶正反轉霍爾信號和電位器輸出功能(無刷直流電機專(zhuan)用(yong))
→可選帶閉合鎖定
→帶軟膠(jiao)扳機
◆Optional with the function or accessory as follows:.
→On-off with linear potentiometer
→On-off with Reversing Signal and linear potentiometer output
(Special for DC brushless motor)
→On-off with Reversing Hall Signal and linear potentiometer output
(Special for DC brushless motor)
→Optional with Lock-on button
→Trigger covered with rubber (overmolding)
技術數據Technical data
→機械耐(nai)久壽(shou)命 Mechanical life endurance≥1E5
→電氣耐久壽命 Electrical life endurance≥5E4
→最大電流 Max. currentat 60Vd.c30A
→最大電流 Max. currentat 130Vd.c25A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度(du) Ambie nt temperature0°C~55°C
→阻燃(ran)等級 FlammabilityUL 94V-0
→防護等級(ji) Protection typeIP40
◆開關(guan)內部電子(zi)部分在(zai)相(xiang)應(ying)使用(yong)中一并做過相(xiang)關(guan)測試,本開關(guan)適(shi)合做二類器具開關(guan)使用(yong).
◆ The electronics in the switches had to be tested together with the corresponding appliances, so the switches are suitable for appliance of class II.
端子類型Terminals
◆輸(shu)入端/輸(shu)出端 Input side/Output side:
→焊接端子 Solder terminal 4.7×0.8mm
→沾(zhan)錫(xi)導(dao)線 Wire with tin conductor
◆電(dian)位器(qi)輸出 Potentiometer Output:
→沾錫導線 Wire with tin conductor
→帶插頭導線 Wire terminal with Plug
★本產品榮獲多項實(shi)用新型專利，專利號：ZL201920301963.3，ZL201922101556.0
★Utility Models patented with the no. is ZL201920301963.3, ZL201922101556.0
電氣參數和認證 Electric Rating and Certification
