產品描述Product description
◆DPK-S系列(lie)是(shi)一款通(tong)用型的直流信號扳機開關(guan)，集成(cheng)防塵功(gong)能，內部帶(dai)換向結構，特別應用于各(ge)類直流無刷充電式手持電動工具和園(yuan)林工具，如：無刷充電式電鉆(zhan)、無刷充電式電錘、無刷充電式螺絲(si)起(qi)子、無(wu)刷(shua)充電式沖擊扳手、無(wu)刷充電式打(da)草機、無刷(shua)充(chong)電式吹(chui)風機(ji)等(deng)。
◆DPK-S?series are general type DC signal trigger switches,integrated dustproof?and reversing box, specially for used in DCcordless?brushless?portable power-tools and gardening tools such as: Cordless?brushless?Drills, Cordless?brushless?Screw Drivers, Cordless,Rotary Hammers, Cordless?brushless?Impact Wrenches,Cordless?brushless?grass trimmer, Cordless?brushless?blowers,etc.
產品特征Features
◆可選帶以下功能或附件:
→信號通斷帶電位器輸出功能
→信號通斷帶正反轉信號和電位器輸出功能
→信號通斷帶正反轉霍爾(er)信(xin)號和電位器輸出功能
→霍爾信號通斷帶正反轉霍爾信號和霍(huo)爾電位器輸出功能
→可選帶閉合鎖定
→帶軟膠扳機
◆Optional with the function or accessory as follows:.
→On-off with linear potentiometer
→On-off with Reversing Signal and linear potentiometer output
→On-off with Reversing Hall Signal and linear potentiometer output
→Optional with Lock-on button
→Trigger covered with rubber (overmolding)
技術數據Technical data
→機械耐久壽命 Mechanical life endurance≥1E5
→電氣耐(nai)久壽命 Electrical life endurance≥5E4
→最(zui)大電流 Max. current0.1A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣(yuan)電阻 Insulation resistance≥7M Ohm
→基(ji)本介電強(qiang)度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~55°C
→阻(zu)燃等(deng)級 FlammabilityUL 94V-0
→防護(hu)等級 Protection typeIP40
◆開關(guan)內部電子部分在(zai)相應使用中一并做過(guo)相關(guan)測試,本開關(guan)適合做二類器具開關(guan)使用.
◆The electronics in the switches had to be tested together with the corresponding appliances, so the switches are suitable for appliance of class II.
端子類型Terminals
◆輸(shu)入端(duan)/輸(shu)出端(duan) Input side/Output side:
→帶(dai)插頭導線 Wire terminal with Plug
★本產品(pin)榮獲實用新(xin)型專利，專利號：ZL201922328152.5
★Utility Model patented with the no. is?ZL201922328152.5
電氣參數和認證 Electric Rating and Certification
