產品描述Product description
◆DPW系列(lie)是一(yi)款通用型(xing)的直流扳機開關，集成防塵和快速剎車接點，應用于(yu)需要快速剎車的直流充(chong)電(dian)式手持電(dian)動工具，如：充(chong)電(dian)式電(dian)圓鋸、充(chong)電(dian)式往復鋸、充(chong)電(dian)式電(dian)鏈鋸等。
◆DPW series are general type DC trigger switches, integrated dustproof, with snap action brake contact, specially for used in DC cordless portable power-tools such as: Cordless Circular Saws, Cordless Reciprocating Saws, Cordless Chain Saws, etc.
產品特征Features
◆可選帶以下功能或附件:
→通斷帶快速剎(cha)車功能
→通斷帶(dai)快速剎車(che)和電位器輸出功能
→外接二極管
→外接導線
◆ Optional with the function or accessories as follows:.
→On-off with snap action brake contact
→On-off with snap action brake contact and linear potentiometer
→External Diode
→External Wires
技術數據Technical data
→機械耐久壽命(ming) Mechanical life endurance≥1E5/5E4
→電氣耐久(jiu)壽命 Electrical life endurance≥5E4/25E3
→最大(da)電(dian)流(liu) Max.current at 24Vd.c35A
→最大電流 Max.current at 42Vd.c30A
→最(zui)大(da)電流 Max.current at 84Vd.c30A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介(jie)電強度(du) Dielectric strength of function1300V
→加(jia)強介電強度(du) Dielectric strength of reinforced2600V
→環境溫(wen)度 Ambient temperature0°C~55°C
→阻燃等(deng)級(ji) FlammabilityUL 94V-0
→防護(hu)等級 Protection typeIP40
◆開(kai)關(guan)內部(bu)電子部(bu)分在(zai)相(xiang)應(ying)使用(yong)中一并做過相(xiang)關(guan)測(ce)試，本開(kai)關(guan)適合做二類(lei)器具開(kai)關(guan)使用(yong).
◆The electronics in the switches had to be tested together with the corresponding appliances, so the switches are suitable for appliance of class II.
端子類型Terminals
◆輸(shu)入端/輸(shu)出(chu)端 Input side/Output side:
→焊(han)接端(duan)子 Solder terminal 4.7×0.8mm
→沾(zhan)錫導線 Wire with tin conductor
◆電位器輸出(chu) Potentiometer Output:
→沾錫導線(xian) Wire with tin conductor
→帶插頭導線(xian) Wire terminal with Plug
★本產品榮獲實用新(xin)型(xing)專利，專利號：ZL202123076617.6
★Utility Model patented with the no. is ZL202123076617.6
電氣參數和認證 Electric Rating and Certification
