產品描述Product description
◆DRK系列(lie)是一款(kuan)專用型的(de)直流信號(hao)扳(ban)機開關，集成防塵(防(fang)水)功能，是為直(zhi)流無刷充(chong)電式電動(dong)工具(ju)和園林工具(ju)特別(bie)設計的，可(ke)適用(yong)于(yu)：無刷充(chong)電式電鉆、無刷充電(dian)式電(dian)錘、無(wu)刷(shua)充電(dian)式螺絲起子(zi)、無(wu)刷電(dian)式沖擊扳手、無刷充(chong)電式吹吸機等。
◆DRK series are one special type DC signal trigger switches, integrated dustproof (and waterproof), designed specially for used in Brushless DC power-tools or Gardening Tools such as: Brushless Cordless Drills, Brushless Cordless Hammers, Brushless Cordless Screw Drivers, Brushless Cordless Impact Wrenches, Brushless Cordless Blowers, etc.
產品特征Features
◆本開關(guan)結構緊湊(cou)，可選帶(dai)以下功能或附件：
→信號通(tong)斷(duan)帶電位(wei)器(qi)輸出功能
→信(xin)號(hao)通斷帶正反轉信(xin)號(hao)輸出和(he)電位器輸出功能
→帶軟膠(jiao)扳(ban)機
◆The switches combine compact size, optional with the function or accessories as follows:
→Signal On-off with linear pote ntiometer
→Signal On-off with Reversing and linear potentiometer
→Trigger covered with rubber (overmolding)
技術數據Technical data
→機械耐(nai)久壽命(ming) Mechanical life endurance≥1E5
→電氣耐(nai)久壽(shou)命 Electrical life endurance≥5E4
→最大(da)電(dian)流(liu) Max. current at 130Vd.c0.1A
→接觸電阻(zu) Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介(jie)電強度 Dielectric strength of function500V
→加(jia)強介電強度 Dielectric strength of reinforced500V
→環境溫(wen)度(du) Ambient tempe rature0°C~55°C
→阻燃(ran)等級 FlammabilityUL 94V-0
→防護等級 Protection typeMax.?IP65/IP67
→開(kai)(kai)關(guan)內部電子部分在相應使用(yong)中一并做過相關(guan)測(ce)試，本開(kai)(kai)關(guan)適(shi)合做二(er)類器具開(kai)(kai)關(guan)使用(yong).
→The electronics in the switches are to be tested together with the corresponding appliance, the switches are suitable for appliance of class II.
端子類型Terminals
◆輸入端/輸出端 Input side/Output side:
→帶插頭(tou)導線 Wire terminal with Plug
→線路板焊接端子(zi) PCB Solder terminal 1.0×0.6mm
★本產品榮(rong)獲實用新型專(zhuan)利(li)，專(zhuan)利(li)號：ZL201821441451.9
★Utility Model patented with the no. is?ZL201821441451.9
電氣參數和認證 Electric Rating and Certification
