產品描述Product description
◆DRK系列是(shi)一款專(zhuan)用型的直流信號扳(ban)機開關，集(ji)成防塵(防水(shui))功能，是為直流(liu)無刷充電(dian)式電(dian)動(dong)工具(ju)和(he)園(yuan)林工具(ju)特別設計的(de)，可適(shi)用(yong)于：無刷充(chong)電(dian)式電(dian)鉆、無刷充(chong)電(dian)式電(dian)錘、無刷(shua)充(chong)電式螺絲起子、無刷(shua)電式沖擊(ji)扳手、無刷充電式吹吸機等。
◆DRK series are one special type DC signal trigger switches, integrated dustproof (and waterproof), designed specially for used in Brushless DC power-tools or Gardening Tools such as: Brushless Cordless Drills, Brushless Cordless Hammers, Brushless Cordless Screw Drivers, Brushless Cordless Impact Wrenches, Brushless Cordless Blowers, etc.
產品特征Features
◆本開(kai)關(guan)結(jie)構緊湊(cou)，可選(xuan)帶以下功能或附件：
→信號通(tong)斷(duan)帶電位(wei)器輸出功能
→信(xin)號通斷(duan)帶正反轉信(xin)號輸出和電位器輸出功能(neng)
→帶軟膠扳機
◆The switches combine compact size, optional with the function or accessories as follows:
→Signal On-off with linear pote ntiometer
→Signal On-off with Reversing and linear potentiometer
→Trigger covered with rubber (overmolding)
技術數據Technical data
→機械耐久壽(shou)命 Mechanical life endurance≥1E5
→電(dian)氣耐(nai)久壽命 Electrical life endurance≥5E4
→最大電流 Max. current at 130Vd.c0.1A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣(yuan)電(dian)阻 Insulation resistance≥7M Ohm
→基(ji)本介電(dian)強度 Dielectric strength of function500V
→加強介電強度 Dielectric strength of reinforced500V
→環境溫度(du) Ambient tempe rature0°C~55°C
→阻燃(ran)等級 FlammabilityUL 94V-0
→防護等級 Protection typeMax.?IP65/IP67
→開關(guan)內部(bu)電子部(bu)分(fen)在相應使用中一并做過(guo)相關(guan)測試，本開關(guan)適合(he)做二類器具開關(guan)使用.
→The electronics in the switches are to be tested together with the corresponding appliance, the switches are suitable for appliance of class II.
端子類型Terminals
◆輸入端/輸出端 Input side/Output side:
→帶插(cha)頭導(dao)線 Wire terminal with Plug
→線路板焊接端(duan)子 PCB Solder terminal 1.0×0.6mm
★本產品榮獲(huo)實用新(xin)型專利(li)，專利(li)號(hao)：ZL201821441451.9
★Utility Model patented with the no. is?ZL201821441451.9
電氣參數和認證 Electric Rating and Certification
