◆可選帶以下功能或附件：
→信號通斷帶電位器輸出功能
→信號通斷帶正反轉信號輸出和電位器輸出功能
→信號剎車
→帶(dai)軟膠扳機
◆Optional with the function or accessories as follows:
→Signal On-off version with linear potentiometer
→Signal On-off version with Reversing and linear potentiometer
→Signal Brake
→Trigger covered with rubber (overmolding)

→機械耐久壽命 Mechanical life endurance≥5E4
→電氣耐久壽命 Electrical life endurance≥1E4
→最大電流 Max. current at 42Vd.c 0.1A
→接觸電阻 Contact resistance ≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function500V
→加強介電強度 Dielectric strength of reinforced500V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40

◆開關(guan)內部電子部分在相應(ying)使用(yong)中--并做過相關(guan)測試(shi),本開關(guan)適合做二(er)類器具開關(guan)使用(yong).

◆The electronics in the switches had to be tested together with the corresponding appliances, so the switches are suitable for appliance of class II.

◆輸入端/輸出端 Input side/Output side:
→導線端子 Wire terminal
→帶插頭導線端子 Wire terminal with Plug
★本產品(pin)榮獲實用(yong)新型專(zhuan)利，專(zhuan)利號：ZL202122394665.3
★Utility Model patented with the no. is ZL202122394665.3
