產品描述Product description
◆FA1-6D系列是(shi)一款通用型的扳(ban)機開關，內(nei)部為快速動作結構，應用于對防(fang)塵不做要(yao)求的手持式電(dian)動(dong)工具(ju)(ju)和園林工具(ju)(ju)，如(ru)：攪拌器、電(dian)動(dong)釘(ding)槍(qiang)、打草機、電(dian)鏈鋸、電(dian)動(dong)割草機、電(dian)動(dong)掃雪機等(deng)。
◆FA1-6D ;series are one general type trigger switch, with with snap-action structure, for used in portable power-tools and gardening tools such as Electric Mixers, Electric Nailers, Grass Trimmers, Electric Chain Saws, Electric Lawnmowers, Electric Snowthrowers, etc.
產品特征Features
◆可選帶(dai)以下鎖定類型 Optional with following lock types:
→無鎖定(ding) NoLock
→閉合鎖(suo)定(ding) Lock-on
技術數據Technical data
→機械耐久壽命 Mechanical life endurance≥1E5
→電氣耐久壽命(ming) Electrical life endurance≥5E4
→最(zui)大沖(chong)擊電(dian)流 Max. Inrush current at 250V78A
→最大沖擊電(dian)流 Max. Inrush current at 125V96A
→接(jie)觸電(dian)阻(zu) Contact resistance≤30m Ohm
→絕緣電(dian)阻 Insulation resistance≥7M Ohm
→基本介電強(qiang)度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~55°C
→阻(zu)燃(ran)等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→適用(yong)于II類防護器(qi)具 Suitable for appliances of protection class II
端子類型Terminals
◆輸入端(duan)Input side:
→2×接線柱端子Pillar terminalsφ=2.8mm
→4×插(cha)(cha)入式端(duan)子(zi)可插(cha)(cha)入沾錫導(dao)線、帶插(cha)(cha)片端(duan)子(zi)導(dao)線或銅包頭導(dao)線
4×Push-in terminals for sold ered strands, strands with end sleeves or strands with end claws
◆輸出端Output side:
→2×接線柱(zhu)端子Pillar terminalsφ=2.8mm
→4×插(cha)入式(shi)端(duan)子可插(cha)入沾錫導線(xian)、帶插(cha)片(pian)端(duan)子導線(xian)或銅包頭(tou)導線(xian)
4×Push-in terminals for soldered strands, strands with end sleeves or strands with end claws
電氣參數和認證 Electric Rating and Certification
