產品描述Product description
◆FA1-6D系列是一款通(tong)用型的扳機(ji)開關(guan)，內部為快速(su)動作結(jie)構(gou)，應用于(yu)對防塵不做要求的手持式(shi)電(dian)(dian)(dian)動工(gong)具和園林工(gong)具，如：攪拌器、電(dian)(dian)(dian)動釘槍、打草機(ji)、電(dian)(dian)(dian)鏈(lian)鋸(ju)、電(dian)(dian)(dian)動割草機(ji)、電(dian)(dian)(dian)動掃雪機(ji)等(deng)。
◆FA1-6D series are one general type trigger switch, with with snap-action structure, for used in portable power-tools and gardening tools such as Electric Mixers, Electric Nailers, Grass Trimmers, Electric Chain Saws, Electric Lawnmowers, Electric Snowthrowers, etc.
產品特征Features
◆可選(xuan)帶以下鎖(suo)定類型 Optional with following lock types:
→無鎖定 NoLock
→閉合鎖定 Lock-on
技術數據Technical data
→機械耐久壽(shou)命 Mechanical life endurance≥1E5
→電氣耐(nai)久壽命 Electrical life endurance≥5E4
→最(zui)大沖擊電流(liu) Max. Inrush current at 250V78A
→最大沖擊(ji)電(dian)流 Max. Inrush current at 125V96A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本(ben)介(jie)電強度(du) Dielectric strength of function1500V
→加強(qiang)介(jie)電強(qiang)度 Dielectric strength of reinforced3000V
→環境溫度(du) Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→適用于II類(lei)防護器具 Suitable for appliances of protection class II
端子類型Terminals
◆輸(shu)入端Input side:
→2×接(jie)線(xian)柱端子(zi)Pillar terminalsφ=2.8mm
→4×插(cha)入(ru)式端(duan)(duan)子可插(cha)入(ru)沾錫導(dao)線(xian)、帶插(cha)片端(duan)(duan)子導(dao)線(xian)或(huo)銅包頭導(dao)線(xian)
4×Push-in terminals for sold ered strands, strands with end sleeves or strands with end claws
◆輸出端Output side:
→2×接線柱(zhu)端子Pillar terminalsφ=2.8mm
→4×插入(ru)式(shi)端(duan)子可插入(ru)沾錫導(dao)(dao)線(xian)(xian)、帶(dai)插片端(duan)子導(dao)(dao)線(xian)(xian)或銅包頭導(dao)(dao)線(xian)(xian)
4×Push-in terminals for soldered strands, strands with end sleeves or strands with end claws
電氣參數和認證 Electric Rating and Certification
