產品描述Product description
◆FA2-6B系列是一款通(tong)用型的扳機開關，集成防(fang)塵功能，廣(guang)泛應用于各類電(dian)(dian)動(dong)工具，如：型材切(qie)(qie)割機(ji)、斜切(qie)(qie)鋸、電(dian)(dian)圓鋸、電(dian)(dian)錘(chui)等。
◆FA2-6B series are one general type trigger switch, integrated dust-proof, commonly for used in power tools such as Cut-off Machines, Miter Saws, Circular Saws, Electric Hammers, etc.
產品特征Features
◆可選(xuan)帶以下功能 Optional with following function:
→單極常開(kai) SPNO
→單極雙擲 SPDT
→一(yi)(yi)極(ji)常開，另一(yi)(yi)極(ji)直通 One Pole NO, the other Directly
→一(yi)極(ji)雙擲，另一(yi)極(ji)直通 One Pole DT, the other Directly
◆可(ke)選帶以下附件 Optional with the accessories as follows:
→包軟(ruan)膠扳機(ji) Trigger covered with rubber (overmolding)
技術數據Technical data
→機械耐久壽命Mechanical life endurance≥1E5
→電氣耐久壽命Electrical life endurance≥5E4
→最大沖擊電流Max.Inrush current at 250V60A
→最大沖擊電流Max.Inrush current at 125V90A
→接觸電阻Contact resistance≤30m Ohm
→絕緣電阻Insulation resistance≥7M Ohm
→基本介電強度Dielectric strength of function1500V
→加強介電強度Dielectric strength of reinforced3000V
→環境溫度Ambient temperature0°C~55°C
→阻燃等級FlammabilityUL 94V-0
→防護等級Protection typeIP40
→適用于II類防護器具Suitable for appliances of protection class II
端子類型Terminals
◆輸入(ru)端(duan)/輸出端(duan) Input side/Output side:
→接線柱端子 Pillar terminals φ=3.0mm
電氣參數和認證 Electric Rating and Certification
