產品描述Product description
◆FA7-10系列是(shi)一(yi)款通用型的扳機開關，內(nei)部為快速動作(zuo)結(jie)構(gou)，可(ke)選(xuan)內部集(ji)成防(fang)塵功(gong)能(neng)，應用(yong)于對防(fang)塵要求較低(di)的電(dian)動(dong)工(gong)具(ju)和園林工(gong)具(ju)，如：攪(jiao)拌器、電(dian)圓鋸、曲線鋸、拋光機、電(dian)刨、電(dian)錘、電(dian)鎬、型材切割(ge)機、斜切鋸、電(dian)鏈鋸、電(dian)動(dong)割(ge)草機等。
◆FA7-10?series are one general type trigger switch,?with snap-action structure,?optional integrated dustproof, for used in power-tools and gardening tools such as Electric Mixers, Circular Saws,Jig Saws, Polishers Grinders, Electric Planers, Rotary Hammers,?Demolition Hammers, Miter Saws, Cut-off Machines, Electric Chain Saws, Electric Lawnmowers, etc.
產品特征Features
◆可選帶以下鎖定類(lei)型 Optional with following lock types:
→無鎖定 No Lock
→閉合鎖定 Lock-on
→斷開鎖定 Lock-off
◆可選帶以(yi)下功能或附(fu)件?Optional with following function or accessories:
→雙極常開 DPNO
→單極常開 SPNO
→一極常開，另一極常閉?One Pole Normally Open, the other normally close
→帶軟膠(jiao)扳(ban)機(ji) Trigger covered with rubber (Overmolding)
技術數據Technical data
→機(ji)械耐久(jiu)壽命(ming) Mechanical life endurance≥1E5
→電氣耐(nai)久壽(shou)命 Electrical life endurance≥5E4
→最(zui)大沖擊電流(liu) Max. Inrush current at 250V90A
→最大沖(chong)擊(ji)電流 Max. Inrush current at 127V120A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣(yuan)電阻 Insulation resistance≥7M Ohm
→基(ji)本介電強(qiang)度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境(jing)溫度 Ambient temperature0°C~55°C
→阻燃等級(ji) FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→適用于II類防護(hu)器具 Suitable for appliances of protection class II
端子類型Terminals
◆輸(shu)入端(duan)/輸(shu)出端(duan)Input side/Output side:
→接線柱端子Pillar terminals φ =3.5mm
★本產品榮獲實用新型專(zhuan)利，專(zhuan)利號：ZL201920475212.3
★Utility Model patented with the no. is?ZL201920475212.3
電氣參數和認證 Electric Rating and Certification
