產品描述Product description
◆FA5-10A, FA5-10B系列是一(yi)款通用性(xing)的扳機開關，集成防塵功能，內部為快(kuai)速動作(zuo)結構，適合(he)一般(ban)功率的電動工具(ju)，如：型材切(qie)(qie)割(ge)機(ji)、斜切(qie)(qie)鋸(介(jie)鋁機(ji))、125和150角磨機(ji)、電錘、電鎬等(deng)。
◆FA5-10A, FA5-10B series are one general type trigger switch, integrated dustproof, with snap-action structure, for used in portable or bench top power-tools such as Cut-off Machines, Miter Saws, 125mm and 150mm Angle Grinders, Rotary Hammers, Demolition Hammers, etc.
產品特征Features
◆有多種支架和扳機可選 Optional with different supports and triggers
◆可選帶以下鎖定類(lei)型(xing) Optional with following lock types:
→無鎖 No Lock
→閉(bi)合鎖定 Lock-on
→斷開鎖(suo)定(ding) Lock-off
技術數據Technical data
→機械(xie)耐久(jiu)壽命 Mechanical life endurance≥1E5
→電氣耐(nai)久壽(shou)命 Electrical life endurance≥5E4
→最(zui)大(da)沖擊電流 Max. Inrush current at 250V60A
→最大沖擊電(dian)流 Max. Inrush currentat 125V90A
→接觸電阻 Contact resistance≤30m Ohm
→絕(jue)緣電阻 Insulation resistance≥7M Ohm
→基本介電強(qiang)度 Die lectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環(huan)境溫度 Ambient temperature0°C~55°C
→阻燃(ran)等級 FlammabilityUL 94V-0
→防(fang)護等級 Protection typeIP40
→適用于II類防護器具 Suitable for appliances of protection class II
端子類型Terminals
◆輸入端(duan)/輸出端(duan) Input side/Output side:
→螺(luo)釘端子 Screw terminals M4
電氣參數和認證 Electric Rating and Certification
