產品描述Product description
◆FA5-10A, FA5-10B系列是一款(kuan)通用性(xing)的扳機開(kai)關，集成(cheng)防塵(chen)功能(neng)，內(nei)部為快速動(dong)作結構，適合一般功率(lv)的電動工(gong)具，如：型材切(qie)割機(ji)(ji)、斜切(qie)鋸(介鋁機(ji)(ji))、125和150角磨機(ji)(ji)、電錘、電鎬(hao)等(deng)。
◆FA5-10A, FA5-10B series are one general type trigger switch, integrated dustproof, with snap-action structure, for used in portable or bench top power-tools such as Cut-off Machines, Miter Saws, 125mm and 150mm Angle Grinders, Rotary Hammers, Demolition Hammers, etc.
產品特征Features
◆有多種支架和扳(ban)機(ji)可選(xuan) Optional with different supports and triggers
◆可選(xuan)帶以下鎖(suo)定(ding)類型 Optional with following lock types:
→無鎖 No Lock
→閉合鎖定(ding) Lock-on
→斷開鎖定 Lock-off
技術數據Technical data
→機械耐(nai)久壽命 Mechanical life endurance≥1E5
→電氣耐久壽命 Electrical life endurance≥5E4
→最大沖(chong)擊(ji)電流(liu) Max. Inrush current at 250V60A
→最(zui)大沖(chong)擊電流 Max. Inrush currentat 125V90A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻(zu) Insulation resistance≥7M Ohm
→基本介電強度 Die lectric strength of function1500V
→加(jia)強介電強度(du) Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防(fang)護等級 Protection typeIP40
→適用于II類(lei)防護器具 Suitable for appliances of protection class II
端子類型Terminals
◆輸入端/輸出端 Input side/Output side:
→螺釘端(duan)子 Screw terminals M4
電氣參數和認證 Electric Rating and Certification
