FA5-10C-A0

FA5-10C防塵快速動作扳機開關

FA5-10C series Dustproof Snap-action Trigger Switches

產品描述Product description

◆FA5-10C 系列(lie)是一款專用型的扳機開關，集成(cheng)防塵(chen)功能(neng)，適合一般(ban)功(gong)率的臺式和手(shou)持式電(dian)動工具及園(yuan)林工具，如：型(xing)材切(qie)割機、斜(xie)切(qie)鋸(介鋁機)、125、150和180角向磨光(guang)機、拋(pao)光(guang)機、電(dian)圓鋸、電(dian)錘、電(dian)鎬(hao)、電(dian)鏈鋸等。
◆FA5-10C series are general type trigger switches, integrated dustproof, for used in portable or bench top power-tools such as Cut-off Machines, Miter Saws, 125mm, 150mm and 180mm Angle Grinders, Circular Saws, Polishers, Rotary Hammers, Demolition Hammers, Electric Chain Saws, etc.

產品特征Features

◆可選帶以下鎖定類(lei)型 Optional with following lock types:
→無鎖定 No Lock

→閉合鎖定 Lock-on

→斷開(kai)鎖定 Lock-off

技術數據Technical data

→機械耐久壽(shou)命 Mechanical life endurance≥1E5
→電氣耐久(jiu)壽命 Electrical life endurance≥5E4
→最(zui)大(da)沖擊電流 Max. Inrush current at 250V90A
→最大沖擊電流 Max. Inrush current at 127V120A
→接觸電阻(zu) Contact resistance≤30m Ohm
→絕緣電(dian)阻 Insulation resistance≥7M  Ohm
→基本介(jie)電強度 Dielectric strength of function1500V
→加(jia)強介電強度(du) Dielectric strength of reinforced3000V
→環境溫(wen)度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護(hu)等級(ji) Protection typeIP40
→適用于II類防護器具 Suitable for appliances of protection class II

端子類型Terminals

◆輸入(ru)端(duan)/輸出端(duan) Input side/Output side:
→螺(luo)釘(ding)端(duan)子 Screw terminals M4

電氣參數和認證 Electric Rating and Certification

訂貨信息Ordering Information
