FA5-10C-W-A2

FA5-10C防塵快速動作扳機開關

FA5-10C series Dustproof Snap-action Trigger Switches

產品描述Product description

◆FA5-10C?系列(lie)是一款專用(yong)型的扳機(ji)開關，集成防塵功能，適(shi)合一般(ban)功率(lv)的(de)臺式(shi)(shi)和手(shou)持式(shi)(shi)電(dian)動工具(ju)及園林工具(ju)，如(ru)：型材切割機、斜切鋸(介鋁機)、125、150和180角向磨光(guang)機、拋光(guang)機、電(dian)圓鋸、電(dian)錘、電(dian)鎬(hao)、電(dian)鏈(lian)鋸等。
◆FA5-10C?series are general type trigger switches,?integrated dustproof, for used in portable or bench top power-tools such as Cut-off Machines, Miter Saws, 125mm, 150mm and 180mm Angle Grinders, Circular Saws, Polishers, Rotary Hammers, Demolition Hammers, Electric Chain?Saws, etc.

產品特征Features

◆可選帶以下鎖定類型 Optional with following lock types:
→無鎖定 No Lock

→閉合(he)鎖定 Lock-on

→斷開鎖定 Lock-off

技術數據Technical data

→機械耐(nai)久壽命 Mechanical life endurance≥1E5
→電氣耐久壽命 Electrical life endurance≥5E4
→最大沖擊電流 Max. Inrush current at 250V90A
→最大(da)沖擊(ji)電流 Max. Inrush current at 127V120A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M? Ohm
→基本(ben)介電強(qiang)度 Dielectric strength of function1500V
→加強介(jie)電強度 Dielectric strength of reinforced3000V
→環(huan)境(jing)溫(wen)度(du) Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級(ji) Protection typeIP40
→適用于II類防護器具(ju) Suitable for appliances of protection class II

端子類型Terminals

◆輸入(ru)端/輸出端 Input side/Output side:
→螺釘端子(zi) Screw terminals M4

電氣參數和認證 Electric Rating and Certification

訂貨信息Ordering Information
