產品描述Product description
◆FDA系列是一款專用型的倒扳開關，也叫搖桿開關或撥動開關，集成防塵功能，應用于(yu)各類(lei)電(dian)(dian)(dian)動(dong)工(gong)具，如(ru)：100和125角向(xiang)磨光機、電(dian)(dian)(dian)木銑、模具電(dian)(dian)(dian)磨、電(dian)(dian)(dian)錘、電(dian)(dian)(dian)鎬等(deng)。
◆FDA series are one special type Lever switches, integrated dustproof, commonly for used in power-tools such as 100mm and 125mm Angle Grinders, Routers, Die Grinders, Rotary Hammers,Demolition Hammers, etc.
產品特征Features
◆可選帶以下附件 Optional with following accessories:
→防塵套 Dustproof sheath
→安裝螺母 Nut for installation
技術數據Technical data
→機械耐久(jiu)壽命 Mechanical life endurance≥1E5
→電氣耐久壽(shou)命 Electrical life endurance≥5E4
→最大沖擊電流 Max. Inrush current at 250V60A
→最大沖擊電流 Max. Inrush current at 127V96A
→接觸(chu)電阻 Contact resistance≤30m Ohm
→絕緣(yuan)電阻(zu) Insulation resistance≥7M Ohm
→基本(ben)介電強度(du) Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境(jing)溫度 Ambient temperature0°C~55°C
→阻(zu)燃等(deng)級(ji) FlammabilityUL 94V-0
→防護(hu)等級(ji) Protection typeIP40
→適用于II類防護器具 Suitable for appliances of protection class II
端子類型Terminals
◆輸入端/輸出端 Input side/Output side:
→接線柱端子 Pillar terminals φ=3mm
電氣參數和認證 Electric Rating and Certification
