FD3F-1314-P1-T1

FD3F滑動(推拉)開關

FD3F series Slide (Push-pull) Switches

產品描述Product description

◆FD3F系(xi)列是一款通用型(xing)的(de)(de)滑動(dong)開關，也叫推(tui)拉開關或推(tui)撥開關，廣泛(fan)應用于各類需要檔位控制的(de)(de)電(dian)動(dong)工(gong)具(ju)和小家電(dian)，如：熱風槍、吹(chui)(chui)吸(xi)機、電(dian)吹(chui)(chui)風、電(dian)風扇、取(qu)暖器、料理機等。
◆FD3F series are general type slide switches, commonly for used in power-tools and small home appliances such as Heat Guns，Blowers， Hair Dryers， Electric Fans， Electric Heating Apparatus, Cooking Machines, etc.

產品特征Features

◆可選帶(dai)以下功能(neng) Optional with following function:
→單極3檔位 Single Pole 3 Position (SP3P)
→雙極3檔(dang)位 Double Pole 3 Position (DP3P)

技術數據Technical data

→機械耐久(jiu)壽命 Mechanical life endurance≥5E4
→電氣耐久壽(shou)命Electrical life endurance≥1E4
→最大(da)電流 Max. current at 250V10A
→最大電流 Max. current at 125V16A
→接觸(chu)電阻 Contact resistance≤30m Ohm
→絕(jue)緣電(dian)阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環(huan)境(jing)溫度(du) Ambient temperature0°C~85°C
→阻燃等(deng)級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→適用于(yu)II類防護(hu)器(qi)具 Suitable for appliances of protection class II

端子類型Terminals

◆輸(shu)入端/輸(shu)出端 Input side/Output side:
→線路(lu)板焊接端子 PCB Soldering terminals 0.8×0.8mm
→插片(pian)端子 Plug-in terminals 2.8×0.8mm
→焊接端(duan)子 Soldering terminals 2.8×0.8mm

電氣參數和認證 Electric Rating and Certification

訂貨信息Ordering Information
