FDK-2410

FDK滑動(推拉)開關

FDK series Slide (Push-pull) Switches

產品描述Product description

◆FDK系列是一款通(tong)用型的(de)(de)推拉開(kai)關，也叫(jiao)滑動開(kai)關，廣(guang)泛應用于各類需要檔位控制(zhi)的(de)(de)電(dian)(dian)動工具和小家電(dian)(dian)，如：熱風(feng)槍(qiang)、電(dian)(dian)吹(chui)風(feng)等。
◆FDK series are general type slide switches, commonly for used in power-tools and small home appliances such as Heat Guns, Hair Drvers, etc.

技術數據Technical data

→機械耐(nai)久壽命(ming) Mechanical life endurance≥5E4
→電氣(qi)耐久壽命 Electrical life endurance≥1E4
→最大電流 Max. current at 250V10A
→接(jie)觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥100M  Ohm
→基(ji)本介電強度 Dielectric strength of function500V
→加(jia)強(qiang)介電強(qiang)度 Dielectric strength of reinforced500V
→環境溫度 Ambient temperature0°C~85°C
→阻燃(ran)等級 FlammabilityUL 94V-0
→防護(hu)等級 Protection typeIP40
→適用于II類(lei)防(fang)護器具(ju) Suitable for appliances of protection class II

端子類型Terminals

◆輸入(ru)端(duan)/輸出端(duan) Input side/Output side:
→焊接端(duan)子(zi)S oldering terminals φ=2.0mm

電氣參數和認證 Electric Rating and Certification

訂貨信息Ordering Information
