FD2-8GX-D

FD2-8GX(防塵)正反轉倒扳開關

FD2-8GX series (Dustproof) Change-over Lever Switches

產品描述Product description

◆FD2-8GX系列是一款(kuan)專用型的倒扳開(kai)關(guan)，也叫搖桿(gan)開(kai)關(guan)或撥動(dong)(dong)開(kai)關(guan)，應用于各類手持(chi)式電(dian)(dian)動(dong)(dong)工具，如(ru)：電(dian)(dian)動(dong)(dong)沖擊扳手、電(dian)(dian)動(dong)(dong)攪拌器(qi)、電(dian)(dian)動(dong)(dong)葫蘆等。
◆FD2-8GX series are special type Lever switches, also named Toggle switch, commonly for used in portable power-tools such as Electric Wrenches, Electric Mixers, Electric Winches, etc.

產品特征Features

◆可(ke)選帶以下功能 Optional with following function:
→雙極(ji)單(dan)擲 DPST (Double Pole Single Throw)
→雙(shuang)(shuang)極雙(shuang)(shuang)擲 DPDT (Double Pole Double Throw)

→雙(shuang)極雙(shuang)擲帶中(zhong)間(jian)斷開 DPDT with center off

→點動方(fang)式 Momentary act

技術數據Technical data

→機械耐久壽命 Mechanical life endurance≥5E4/1E5
→電(dian)氣(qi)耐(nai)久壽命 Electrical life endurance≥1E4/5E4
→最大沖(chong)擊電流 Max. Inrush current at 250V72A
→最大沖擊電流 Max. Inrush current at 125V108A
→接(jie)觸(chu)電阻 Contact resistance≤30m Ohm
→絕(jue)緣電阻 Insulation resistance≥7M  Ohm
→基本介電強(qiang)度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→適用于II類防護器具 Suitable for appliances of protection class II

端子類型Terminals

◆輸(shu)(shu)入端/輸(shu)(shu)出端 Input side/Output side:
→插片端子 Plug-in terminals 4.8×0.8mm
→螺釘端子(zi) Screw terminals M3.5

電氣參數和認證 Electric Rating and Certification

訂貨信息Ordering Information
