產品描述Product description
◆FD2-12G系(xi)列是(shi)一款專用型的(de)倒扳開關(guan)，也叫搖桿開關(guan)，集成防塵(chen)和(he)防水(shui)功能，廣泛應用于(yu)各類臺(tai)(tai)式電動工具，如：臺(tai)(tai)式推拉鋸、臺(tai)(tai)式圓鋸、臺(tai)(tai)式刨(bao)床(chuang)、臺(tai)(tai)式銑(xian)床(chuang)、臺(tai)(tai)式線鋸、臺(tai)(tai)式鉆床(chuang)、臺(tai)(tai)式車床(chuang)、臺(tai)(tai)式砂輪(lun)機、臺(tai)(tai)式瓷磚切割機、地(di)板鋸等。
◆FD2-12G series are special type Lever switches, integrated dustproof and waterproof, commonly for used in bench top power-tools such as Bench Push-pull Saws, Bench Circular Saws, Bench Planers, Bench Routers, Bench Scroll Saws, Drill Presses, Bench lathes, Bench Grinders, Bench Marble Cutters, Floor Cutters, etc.
產品特征Features
◆可(ke)選(xuan)帶以下(xia)功(gong)能 Optional with following function:
→單極單擲 SPST (Single Pole Single Throw)
→單極雙擲(zhi) SPDT (Single Pole Double Throw)
→單極雙擲(zhi)中間斷(duan)開(kai) SPDT with center off
→雙極(ji)單擲 DPST (Double Pole Single Throw)
→雙極(ji)雙擲 DPDT (Double Pole Double Throw)
→雙極雙擲帶中間(jian)斷開 DPDT with center off
◆可選帶(dai)以下附件 Optional with following accessory:
→兒童安全鎖 Key for children's safety
技術數據Technical data
→機械耐久(jiu)壽(shou)命(ming) Mechanical life endurance≥1E5/ 5E4
→電氣耐久(jiu)壽命 Electrical life endurance≥5E4/ 1E4
→最大(da)沖擊電(dian)流(liu) Max.Inrush current at 250V90A
→最(zui)大沖擊電流(liu) Max.Inrush current at 125V132A
→接觸(chu)電阻 Contact resistance≤30m Ohm
→絕緣電阻(zu) Insulation resistance≥7M Ohm
→基本介電強度(du) Dielectric strength of function1500V
→加強介(jie)電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~55°C
→阻(zu)燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP54
→適(shi)用于II類防護器具(ju) Suitable for appliances of protection class II
端子類型Terminals
◆輸(shu)(shu)入端(duan)/輸(shu)(shu)出端(duan) Input side/Output side:
→插(cha)片端(duan)子 Plug-in terminals 6.3×0.8mm
→插(cha)片端子(zi) Plug-in terminals 4.8×0.8mm
→焊接端子 Soldering terminals 4.8×0.8mm
→螺釘端子(zi) Screw terminals M3.5
電氣參數和認證 Electric Rating and Certification
