產品描述Product description
◆FD2-12G系列是一(yi)款專用型的倒扳開(kai)關，也叫(jiao)搖桿開(kai)關，集(ji)成(cheng)防塵和防水功能，廣(guang)泛(fan)應用于(yu)各類臺(tai)(tai)式(shi)(shi)(shi)電動工具，如：臺(tai)(tai)式(shi)(shi)(shi)推(tui)拉鋸(ju)、臺(tai)(tai)式(shi)(shi)(shi)圓鋸(ju)、臺(tai)(tai)式(shi)(shi)(shi)刨床(chuang)、臺(tai)(tai)式(shi)(shi)(shi)銑床(chuang)、臺(tai)(tai)式(shi)(shi)(shi)線鋸(ju)、臺(tai)(tai)式(shi)(shi)(shi)鉆床(chuang)、臺(tai)(tai)式(shi)(shi)(shi)車床(chuang)、臺(tai)(tai)式(shi)(shi)(shi)砂輪機、臺(tai)(tai)式(shi)(shi)(shi)瓷磚(zhuan)切割機、地板鋸(ju)等。
◆FD2-12G series are special type Lever switches, integrated dustproof and waterproof, commonly for used in bench top power-tools such as Bench Push-pull Saws, Bench Circular Saws, Bench Planers, Bench Routers, Bench Scroll Saws, Drill Presses, Bench lathes, Bench Grinders, Bench Marble Cutters, Floor Cutters, etc.
產品特征Features
◆可選(xuan)帶以(yi)下功能 Optional with following function:
→單(dan)極單(dan)擲 SPST (Single Pole Single Throw)
→單極雙(shuang)擲 SPDT (Single Pole Double Throw)
→單極(ji)雙擲中(zhong)間斷(duan)開 SPDT with center off
→雙極單(dan)擲 DPST (Double Pole Single Throw)
→雙(shuang)極雙(shuang)擲 DPDT (Double Pole Double Throw)
→雙極雙擲帶中(zhong)間斷開 DPDT with center off
◆可選(xuan)帶以下附件(jian) Optional with following accessory:
→兒童安(an)全(quan)鎖 Key for children's safety
技術數據Technical data
→機械耐(nai)久壽命(ming) Mechanical life endurance≥1E5/ 5E4
→電(dian)氣(qi)耐久壽命 Electrical life endurance≥5E4/ 1E4
→最大沖(chong)擊(ji)電流 Max.Inrush current at 250V90A
→最(zui)大(da)沖擊電流(liu) Max.Inrush current at 125V132A
→接(jie)觸(chu)電阻 Contact resistance≤30m Ohm
→絕緣電阻(zu) Insulation resistance≥7M Ohm
→基本介電強(qiang)度 Dielectric strength of function1500V
→加強(qiang)介電強(qiang)度(du) Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級(ji) FlammabilityUL 94V-0
→防護等級 Protection typeIP54
→適(shi)用于II類防(fang)護器(qi)具 Suitable for appliances of protection class II
端子類型Terminals
◆輸(shu)入端/輸(shu)出(chu)端 Input side/Output side:
→插片(pian)端子(zi) Plug-in terminals 6.3×0.8mm
→插(cha)片(pian)端子 Plug-in terminals 4.8×0.8mm
→焊接端子(zi) Soldering terminals 4.8×0.8mm
→螺(luo)釘端子 Screw terminals M3.5
電氣參數和認證 Electric Rating and Certification
