產品描述Product description
◆K1-6D系列(lie)是一款標(biao)準(zhun)型(xing)(xing)的小型(xing)(xing)蹺板開關(guan)，也通稱(cheng)船(chuan)型(xing)(xing)開關(guan)、波形開關(guan)等(deng)，用途極(ji)廣，可選帶防護罩實(shi)現防塵(chen)防水，可應用于各類小家(jia)電(dian)及(ji)辦公設備，如：手持吸(xi)塵器(qi)、臺燈、電(dian)風(feng)扇(shan)、打印(yin)機、游戲(xi)機、電(dian)腦電(dian)源、有(you)源音箱等等。
◆K1-6D series are one standard type rocker switch, optional with Protection Cap for dustproof and waterproof, commonly for used in small Home appliances, such as Portable Vacuum Cleaners，Reading Lamps, Electric Fans, Printers, Computer Power-supplys, Power Sound Box, etc.
產品特征Features
◆可選帶以下功能 Optional with the function as follows:
→單(dan)(dan)極(ji)單(dan)(dan)擲 SPST (Single Pole Single Throw)
→單極雙(shuang)擲 SPDT (Single Pole Double Throw)
→單極雙擲帶中間斷開 SPDT with Centre-off
→點(dian)動功能 Momentary act
◆可選(xuan)帶以下附件 Optional with the accessories as follows:
→防護罩 Protection Cap
→焊接帶端子導(dao)線 Soldering with leads and terminals
技術數據Technical data
→機械耐久壽命(ming) Mechanical life endurance≥1E5
→電氣耐久壽命 Electrical life endurance≥1E4
→最(zui)大沖擊電(dian)流 Max. Inrush current at 250V48A
→最(zui)大沖擊(ji)電流 Max. Inrush current at 125V48A
→接(jie)觸電(dian)阻(zu) Contact resistance≤30m Ohm
→絕(jue)緣電阻(zu) Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介(jie)電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~85°C
→操動件溫度 Actuator temperature0°C~55°C
→阻燃(ran)等級(ji) FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→適用于II類防護器具 Suitable for appliances of protection class II
端子類型Terminals
◆輸入端/輸出(chu)端 Input side/Output side:
→插片端子 Plug-in terminals 4.8×0.8mm
→焊接端子 Solder terminals 4.8×0.8mm
→焊接(jie)端子 Solder terminals 3.0×0.8mm
電氣參數和認證 Electric Rating and Certification
